The eyepiece is replaceable and the objective lens has two levels of magnification, which can obtain three magnifications of 10X.16X and 25.6X to meet the needs of whole-eye examination and fine examination.
There is an accessory interface at the top of the objective lens, which can hang various models of posterior segment laser adapter and Goldman IOP meter.
The light source adopts OSRAM positioning tungsten halogen bulb, the optical lens is made of Schott glass, and the multi-layer coating process is used to enhance the transmittance, the advanced optical process ensures uniform brightness and clear field of view.
| Model | Slit Lamp YZ5F |
|---|---|
| Eye Piece | 10× and 16× |
| Magnifications | 10×(ø18mm), 16×(ø14.5mm), 16×(ø11.25mm), 25.6×(ø9mm) |
| Pupil Distance | 10× Eye Piece 55mm~82mm |
Microscope Type: Converging Stereoscopic Microscope
Objective Magnification: Two steps magnifications
Eye Piece: 10× and 16×
Magnifications: 10×(ø18mm), 16×(ø14.5mm), 16×(ø11.25mm), 25.6×(ø9mm)
Pupil Distance: 10× Eye Piece 55mm~82mm; 16× Eye Piece 51mm~78mm
Diopter Adjustment: 10× Eye Piece +8D; 16× Eye Piece +10D
Slit Width: 0mm~9mm adjustable
Slit Height: 1mm~8mm adjustable
Slit Angle: 0° ~ 180° adjustable
Slit Inclination: 5°, 10°, 15°, 20° four steps
Diameter of Light Spot: ø9mm, ø8mm, ø5mm, ø3mm, ø2mm, ø1mm, ø0.2mm
Filter: Heat Absorption, Grey, Redfree, Cobalt Blue
Illumination Source: 12V30W Halogen Source
Power Supply: AC110V/220V +10%, 50Hz/60Hz
Total Weight: 23Kgs
Packing Volume: 72*50*48cm
